Products
LM-4K100T/R
4K 100 TR HDBaseT Extender is engineered with professional AV installers in mind.Boasting a range of features that streamline system integration, verification,and maintenance, it stands out as one of the slimmest HDBaseT extenders available worldwide—offering exceptional flexibility and remarkable functionality.
LM-B12AE
1, supporting 1-in 2-out signal distribution
2, support video up to 4K @ 60Hz 8bit RGB, YCbCr 4:4:4/4:2:2
3. Output end supports independent 4K to 2K down-conversion
4. Support up to 7.1 channels of common embedded audio, such as LPCM, Dolby TrueHD, DTS-HD, Master Audio, etc.
5, support HDMI embedded audio de-embedded to Toslink optical digital or 3.5 analog stereo audio
6. Support the intelligent EDID management function or copy the connected EDID of the most front output.
7. The front panel is equipped with LED status indicator to intuitively understand the operation status.
8, all ports have perfect ESD electrostatic protection
LM-HB-70T/R
HDBaseT twisted-pair extender is a long-distance HD signal transmitter without compression and delay integrated with HDBaseT technology. HDMI signals are output from the receiving end. The signal resolution is up to 4Kx2K, and the signal can be extended to 70 meters through a single CAT5e/CAT6a cable. It supports CEC function, RS232 two-way communication function and two-way IR control. In addition, it also supports two-way POE function, and power can be supplied at either end.
LM-MJPEG-2T/R
This 4K60 IP distributed audio and video codec is based on JPEG2000 technology. An optical port and an electric port are integrate.
Encoder input supports video resolution up to 4K 60 4:4:4 with audio stripping or embedding. Decoder output support
Video resolution up to 4K 60 4:4:4 with audio stripping. This product supports ARC/eARC/SPDIF/Analog Audio Return. It supports USB 2.0/KVM/camera, 1G Ethernet, bidirectional RS-232, bidirectional infrared and POE functions. Client mode supports RS-232, infrared, and CEC control. Built-in two relay ports and two I/O ports for contact control.
Built-in MJPeg substream supports a large number of API commands for flexible configuration, suitable for third-party control applications to preview video content.
The system is based on Linux for software development, provides flexible control mode, and can be based on the intelligent networking mode of Gigabit Ethernet switch.
LM-WX11-R
1. The host supports access to USB camera, HDMI camera and USB microphone. With TYPE C screen transmitter and HDMI screen transmitter, the Windows client can realize BYOM function and share the camera and microphone wirelessly on Windows/Mac computers. Support MJPEG/H264/H265 USB camera.
2. Support the display of four signal sources at the same time, and realize the split-screen display of four pictures.
3. Support Miracast, AirPlay, DLNA, Chrome and other screen projection methods. Support screen projection with USB/Type-C/HDMI screen transmitter
4.22. The host supports true 4K point-to-point decoding display of single picture, and supports transmission effect of 1080P for each split-screen picture under double/four pictures. Miracast, Airplay, TYPE C, HDMI and USB all support 4K point-to-point screen transmission.
5. Support the connection of touch screen to realize reverse control
6. Provide Windows, Mac, Linux computer client, Android, iOS mobile client. In addition to the screen transmission function, the client can also display the content of the host in reverse, and touch control, support mouse reverse control, and support 10-point touch reverse control.
7. Built-in writing software and annotation software can annotate the screen in real time, and save local, U disk or mobile phone QR Code to share a variety of options. Both writing and annotating have writing acceleration features.
8. Support screen projection across network segments
9. Support centralized control deployment and management
