LM-B414K

The HD0110 is a 1-input, 16-Output Distribution Amplifier for HDMI signals with resolutions up to 4K × 2K @ 60Hz. They support data rates up to 18 Gbps, 3D and HD lossless audio formats, and feature easy-to-integrate features such as automatic input signal equalization, input signal restoration, output signal amplification, and automatic color depth management. Its EDID Manager and Key Manager technologies maintain continuous EDID communication between connected devices and ensure simultaneous distribution of HDCP-encrypted source content.

The HD0104 is a 1-input, 4-output distribution amplifier for HDMI signals with resolutions up to 4K × 2K @ 60Hz. They support the HDMI 2.0b parameter standard, including data rates up to 18 Gbps, color depths up to 8 bits (4K) or 12 bits (1080p), 3D, HD lossless audio formats. This HDCP 1.4-compliant distribution amplifier features an EDID manager and a key manager to maintain continuous EDID communication between connected devices and ensure simultaneous distribution of HDCP-encrypted source content.

This 4K60 IP distributed audio and video codec is based on JPEG2000 technology. An optical port and an electric port are integrate. Encoder input supports video resolution up to 4K 60 4:4:4 with audio stripping or embedding. Decoder output support Video resolution up to 4K 60 4:4:4 with audio stripping. This product supports ARC/eARC/SPDIF/Analog Audio Return. It supports USB 2.0/KVM/camera, 1G Ethernet, bidirectional RS-232, bidirectional infrared and POE functions. Client mode supports RS-232, infrared, and CEC control. Built-in two relay ports and two I/O ports for contact control. Built-in MJPeg substream supports a large number of API commands for flexible configuration, suitable for third-party control applications to preview video content. The system is based on Linux for software development, provides flexible control mode, and can be based on the intelligent networking mode of Gigabit Ethernet switch.
